Multi Core

Light Duty Sheathed Copper Conductor Flexible Cables

Victoria -core cables are manufactured with premium quality and highly flexible copper conductor, Class 5 of IS 8130, suitable for both, industrial and domestic applications. The sheathing material is used to protect the insulated cores from mechanical damage.

The sheathing compound is again specially formulated PVC compound which combines greater flexibility with superior mechanical strength to withstand rigorous use involving impact and abrasion;

yet it is easily separable from cores and special properties like resistance to weathering, fungi, bacteria and termite can be provided for specific conditions and circumstances of use. It is a special grade PVC for high temperature insulation and low power consumption.

FEATURES

  • Approval : IS 694:2010 marked
  • Conductor : As per Class-5, IS 8130:2013
  • Insulation : IS 5831, Type D
  • Marking : Cables are printed with marking of Victoria core (Size Sq.mm) 1100V
  • Colours : 2 Core Red & Black
  • 3 Core : Red, Yellow & Blue
  • 4 Core : Red, Yellow,Blue & Black color PVC ST3 sheath
As Per IS 694:2010 Volatage Grade Upto 1100V
Nom Cross Sectional Area of Conductor No. Nom Dia of cond' strands Thickness of PVC Insulation (Nominal) Thickness of Sheath (Nominal) Overall Diameter (Approx.) Current Rating AC Voltage drop/Amp/ Meter Max. Resistance of Conductor at 200c
2 Core 3 Core 4 Core 2 Core 3 Core 4 Core
sqmm mm mm mm mm mm mm mm mm Amp mv mv Ohm/km
0.5 16/0.20 0.6 0.9 0.9 0.9 6.5 6.8 7.3 5 83 72 39.0
0.75 24 / 0.20 0.6 0.9 0.9 0.9 6.8 7.2 7.7 8 56 48 26.0
1 32/0.20 0.6 0.9 0.9 0.9 7.1 7.6 8.3 13 43 38 19.5
1.5 30/0.25 0.6 0.9 0.9 1.0 7.8 8.3 9.2 16 29 25 13.3
2.5 48/0.25 0.7 1.0 1.0 1.0 9.5 10.1 1.7 20 18 16 7.98
4 56/0.30 0.8 1.0 1.0 1.0 11 11.4 12.3 27 12 9.6 4.95
6 84/0.30 0.8 1.1 1.2 1.2 12.6 13 14.2 34 7.4 6.3 3.3
10 140/0.30 1.0 1.3 1.4 1.4 14.8 16 18 45 4.3 3.8 1.91
16 126/0.40 1.0 1.4 1.4 1.4 17.2 18.3 20.3 61 2.7 2.3 1.21
